Type

Non-Lubricated

Low hydraulic pressure

Double acting, Single rod

Double acting, Double rod

Single acting spring return / Single acting spring extend

Fluid

Air

Turbine Oil VG32

Proof pressure

15kgf/cm² (1.5MPa)

Max. operating pressure

10kgf/cm² (1.0MPa)

5kgf/cm² (0.5MPa)

Min. operating pressure

0.5kgf/cm²(0.05MPa)

0.8kgf/cm²(0.08MPa)

Forward: 1.8kgf/cm²(0.18MPa)

Reverse: 2.3kgf/cm²(0.23MPa)

1.8kgf/cm² (0.18MPa)

Ambient & fluid temperature

5 ~ 60℃

Operating piston speed

50 ~ 750mm/s

15 ~ 300mm/s

Cushion

Rubber bumper

Tolerance of thread

KS class 2
